Hydraulic Hose SAE100 R8
Back to products
27.6
Hydraulic Hose SAE100R13

Hydraulic Hose SAE100R9/R10/R12

  • Tube: Black, oil-resident synthetic rubber (Nitrile)
  • Reinforcement: Four alternating layers of spiraled, high-tensile steel wire.
  • Cover: Black, oil-resistant synthetic(Nitrile).
  • SAE 100 R9/R10/R12 Steel Wire Spiraled Hydraulic Hose Temperature Range: -40℉ to +250℉ (-40℃ to +121℃)
Compare
Add to wishlist
Category: Tags: ,
Description

Hydraulic Hose SAE100R9/R10/R12

SAE 100 R9/R10/R12 Steel Wire Spiraled Hydraulic Hose is suitable for delivering petroleum-based hydraulic oils and it is mainly used in high pressure working conditions. It is composed of three parts: tube, reinforcement and cover. The tube is made from black oil resistant synthetic rubber, making it have outstanding performance in delivering petroleum-based hydraulic oils. The reinforcement is made from four layers of high tensile and high strength thick spiraled steel wire in alternating direction, making the hose resistant to extremely high pressure. The cover is made from high quality synthetic rubber, which is resistant to abrasion, corrosion, weather, ozone, cut, aging and sunlight.



Figure 1. Hydraulic Hose

28.5
28.1

Figure 2. Hydraulic Hose

28.2

Figure 3. Hydraulic Hose



Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Hydraulic Hose SAE100R9/R10/R12”

Your email address will not be published.

SPECIFICATION

Hydraulic Hose SAE100R9/R10/R12

Original:

China

Brand:

Hitech

Period of Guarantee:

12 Month

Features - Benefits:

Extremely high pressure, high impulse hydraulic applications. Exceeds all performance requirements for SAE 100 R9 / R10 / R12, EN856 R9 / R10 / R12, SAE 100 R12 and EN856 4SP. Compatible with biodegradable hydraulic fluids like synthetic esters, polyglycols and vegetable oils as well as petroleum-based fluids.

Application:

Hydraulic system service with petroleum and water-based fluids, for general industrial use

Specification:

Tube: Black, oil-resident synthetic rubber (Nitrile)
Reinforcement: Four alternating layers of spiraled, high-tensile steel wire.
Cover: Black, oil-resistant synthetic(Nitrile).
SAE 100 R9/R10/R12 Steel Wire Spiraled Hydraulic Hose Temperature Range: -40℉ to +250℉ (-40℃ to +121℃)
